Yokogawa|PFCD-E5521|Field Control Unit Detection
SKU: PFCD-E5521

  • Manufacturer: Yokogawa

  • Product No.: PFCD-E5521

  • Condition：In stock

  • Product Type: Field Control Unit Detection

  • Product Origin: Japan

  • Payment:T/T, Western Union

  • Weight: 2000g

  • Shipping port: Xiamen

  • Warranty: 12 months

Product Description

The Yokogawa PFCD-E5521 is a duplexed field control station, equipped with the following technical specifications:

  • Processor: R4300
  • Memory Protection During Power Failure: Main memory is battery-backed, offering up to 72 hours of backup. Recharge time for the battery is at least 48 hours.
  • FCS Status Contact Output: Features 2 terminals (NC, C) which open during FCS failure. Contact rating: 30 V DC, max. 0.3 A.
  • Communication Interface: V net Interface, which can be configured as dual-redundant or single.
  • Power Supply: Options include 100-120 V AC, 50/60 Hz; 220-240 V AC, 50/60 Hz; 24 V DC.
  • Electric Power Consumption: With maximum I/Os installed, power consumption is 200 VA for 100-120 V AC, 300 VA for 220-240 V AC, and 9 A for 24 V DC.
  • Weight: Approximately 13 kg for PFCS and around 16 kg for PFCD.
  • Mounting: 19” Rack Mounting using rack mount (8xM5 screws) and insulation bush (accessory).
  • Connection: Power Supply, Grounding, and Contact Output utilize M4 screw terminal connections.
