Yokogawa | ANB10D-421/CU2N/NDEL | ESB Bus Node Unit

SKU: ANB10D-421/CU2N/NDEL

Manufacturer: Yokogawa
Product No.: ANB10D-421/CU2N/NDEL
Condition：In stock
Product Type: ESB Bus Node Unit
Product Origin: Japan
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Interface Function

Communicates: Analog I/O and contact I/O signals with the FCU via the ESB bus.
Options:
- Voltage: 100-120 V AC or 220-240 V AC
- Frequency: 50/60 Hz
Electric Power Consumption:
- 100-120 V AC: 200 VA, 120 W
- 220-240 V AC: 230 VA, 120 W
- 24 V DC: 5.5 A

Weight

Weight: Approximately 10 kg (including 8 I/O Modules)
Mounting Type: 19-inch rack mount (M5 x 4 screws) with insulation base (accessory)

Node Units Connectable to FCU

ANB10D (ESB Bus Node Units):
- Max. 3 units connected per FCU (AFV30, AFV40)
- Max. 9 units connected per FCU (AFV10, AFF55)
ER Bus Node Units (ANR10):
- Max. 3 units connected per FCU
- Max. 14 units connected per FCU

ESB Bus Node Connection

Install ESB Bus Coupler Module (EC401 or EC402) to the FCU:
- EC401 or EC402 must be installed in slot 7 and slot 8.
- For single configuration, EC401 or EC402 should be in slot 7, and slot 8 must be empty.
- EC402 can be installed in AFV30, AFV40, AFV10, or AFF55.

This structured overview provides a clear and comprehensive description of the Yokogawa ANB10D-421/CU2N/NDEL ESB Bus Node Unit, including its key technical specifications, mounting details, and connection requirements

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
