Yokogawa | AAB841-S50 | Current/Voltage I/O Module (Non-Isolated)

SKU: AAB841-S50

Manufacturer: Yokogawa
Product No.: AAB841-S50
Condition：In stock
Product Type: Current/Voltage I/O Modules
Product Origin: Japan
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Product Description

Model AAB841 (8-channel input/8-channel output, Non-Isolated Differential Input)

I/O Signal:
- Input: 1 to 5 V DC (allowable common mode voltage ±1 V or less)
- Output: 4 to 20 mA
Allowable Input Current/Voltage: ±7.5 V
Input Resistance:
- Power ON: 1 MΩ or larger
- Power OFF: 340 kΩ or larger
Accuracy:
- Input: ±4 mV
- Output: ±48 µA
Data Update Period: 10 ms
Input Step Response Time: 100 ms
Output Step Response Time: 40 ms
Transmitter Power Supply: Not applicable
Temperature Drift: ±0.1 %/10 °C
Maximum Current Consumption: 310 mA (5 V DC), 250 mA (24 V DC)
Weight: 0.3 kg
External Connection: KS cable
HART Communication: Available at Current input and output

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
