Woodward |LR20025|Relay Module

SKU: LR20025

Manufacturer: Woodward
Product No.: LR20025
Condition：In stock
Product Type: Relay Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Description

WOODWARD LR20025, also known as MFR1375M/PMRSU03UV, is a customized multifunctional relay module primarily used in 1.5MW wind turbines. It connects to the upper PLC via CAN bus with a special CAN protocol option Su03.

Features

Mounting: Back panel mounted
Brackets: DIN rail brackets (8923-1023)
Software: Configuration software - LeoPC
Display: 2-line numeric display
Inputs/Outputs:
- 1 x Discrete Input
- 8 x Discrete Output

Technical Specifications

Dimensions: 96 x 72 x 130 mm
Voltage Sensing: 690 VAC
Current Sensing: Up to 5A
Accuracy Class: 1
Communication: CAN bus with protocol Su03
Configuration Cable: 5417-557 DPC-1 or 5417-1251 DPC-USB
