Woodward | 9907-252 | Load Sharing Module

SKU: 9907-252
  • Manufacturer: Woodward

  • Product No.: 9907-252

  • Condition:In stock

  • Product Type: Load Sharing Module

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 2000g

  • Shipping port: Xiamen

  • Warranty: 12 months

Product Description:

Technical Specifications

  • Dimensions: 273.6 mm x 59.2 mm x 214.1 mm
  • Droop: 0 - 11% speed reduction
  • Humidity: Tested at 95%, not condensing
  • Load Sharing Input: 0-3 Vdc
  • Manufacturer: Woodward
  • Power Supply: 18-32 Vdc
  • Sync Input: Compatible with Woodward SPM-A synchronizer

About the 9907-252

The 9907-252 Load Sharing Module is available from our inventory at AX Control Inc. This unit operates with a power supply nominally at 24 Vdc but can range from 18 to 32 Vdc. It features both three-phase PT (Potential Transformer) and CT (Current Transformer) inputs:

  • PT Inputs: 95 to 130 V/AC (line to line)
  • CT Inputs: 3 to 7 A Rms (full load)

Adjustments:

  • Droop: Provides speed reduction from no-load to full-load conditions.
  • Load Gain: Adjusts the load on individual generators when paralleled.

Environmental Specifications:

  • Operating Temperature Range: -40°C to +70°C (-40°F to +158°F)
  • Environmental Suitability: Best suited for stable environments
Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
