Woodward |9907-149 | ProTech Overspeed Trip Device

SKU: 9907-149

Manufacturer: Woodward
Product No.: 9907-149
Condition：In stock
Product Type: ProTech 203 Electronic Overspeed Trip Device
Product Origin: USA
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Description

The Woodward ProTech 9907-149 is a 120 Vac/dc overspeed protection device with a modular design. It features three independent speed-sensing units, each with its own power supply, operator interface, and alarm system. The units use a two-out-of-three voting method for reliable protection.

Features

Modular design for hot replacement and testing.
Three identical speed-sensing units (A, B, and C).
Separate power supplies, interfaces, and alarm systems.
Two-out-of-three voting method.
Magnetic pickups (MPUs) for speed monitoring.
Identical trip points for all units.
Key switch for PROGRAM mode.
Tunable parameters for customization.
NEMA 4 and 4X certified enclosure (IP54 for Europe).

Technical Specifications

Model: 9907-149
Brand: Woodward ProTech
Power Supply: 120 Vac/dc
Speed-Sensing Units: 3
Trip Speed Set Point: 250 rpm to 25,000 rpm
MPU Gear Teeth: 20 to 120
MPU Failed Timeout: 1 sec to 533 min 20 sec
MPU Failed Set Point: 100 rpm to 25,000 rpm
Trip on MPU Failure: Configurable
Timer Starts on Reset: Configurable
Alarm If Speed Is < MPU Failed Set Point: Configurable
Enclosure Certification: NEMA 4, 4X (IP54 for Europe)
Manual: 85204 (Revision G)
