Woodward | 5464-648 | 8 Channel Analog Output Module
Inputs
- Voltage (bus and generator): 115 or 230 Vac rms, 50/60 Hz
- Voltage Tolerance: ±10%
- Power Consumption: 5 W maximum
Outputs
-
Control Compatibility:
- high impedance output for 2301 load sharing controls
- low impedance output for 2301A, EPG, and 2500 load sharing controls, and EGA, and EGM controls with external resistor
- EPG output for EPG controls without load sharing
-
Breaker Close Relay Contact Ratings:
- Resitive Loads: 10 A at 28 Vdc, 3 A at 120 Vac, 50/60 Hz
- Inductive Loads: 6 A at 28 Vdc, 2 A at 120 Vac, 50/60 Hz
- Breaker Close Command Duration: approx. 1 second
Selections and Adjustments
- Operating Modes: RUN, CHECK, PERMISSIVE, OFF
- Synchronizer Reset: automatic reset
- Phase Match Window: ±5°, ±10°, ±15° available
- Match-up Time: 1/8, 1/4, 1/2, 1 second field-selectable internally (factory default is 1/2 second)
- Voltage Matching Range: 0.5%, 1%, 5%, 10% available
Physical Installation
- Location: mount with switch gear
- Weight: 2.2 kg (5 lbs)
- Maximum Operating Temperature Range: −45 to +70 °C (−49 to +158 °F)
- Optimal Operating Temperature Range: +10 to +30 °C (+50 to +86 °F)
Regulatory Compliance North American Compliance:
- UL: UL Listed for use in Ordinary Locations for Canada and the United States. UL File E97783
- CSA: CSA Certified for use in Ordinary Locations in Canada. CSA Certificate LR 46653-12
