TU810V1 | ABB | Compact MTU 50V
SKU: TU810V1

  • Manufacturer: ABB

  • Product No.: TU810V1

  • Condition：In stock

  • Product Type: Compact MTU

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 170g

  • Shipping port: Xiamen

  • Warranty: 12 months

General Info

  • Article number: 3BSE013230R1
  • Type: Compact
  • Connection: Terminal block
  • Channels: 16
  • Voltage: 50 V
  • Mounting: Both directions
  • Mounting detail: Horizontal 55 ºC (131 °F), Vertical 40 ºC (104 °F)
  • Use with I/O: AI810, AI815, AI820, AI830, AI830A, AI835, AI835A, AI845, AO810, AO810V2, AO815, AO820, AO845, AO845A, DI810, DI811, DI814, DI830, DI831, DI840, DI880, DI885, DO810, DO814, DO815, DO840, DO880, DP820, DP840
  • Process connections: 2 x 2 Process power, 5 x 2 Process power (0 V)
  • Single/redundant I/O: Single

Detailed Data

  • Maximum current per I/O channel: 2A
  • Maximum current process connection: 5A
  • Acceptable wire sizes: Solid: 0.2 - 4 mm², Stranded: 0.2 - 2.5 mm², 24 - 12 AWG
  • Dielectric test voltage: 500 V a.c.

Dimensions

  • Width: 64 mm (2.52 in.) including connector, 58.5 mm (2.3 in.) edge to edge installed
  • Depth: 64 mm (2.52 in.) including terminals
  • Height: 170 mm (6.7 in.) including latch
  • Weight: 0.17 kg (0.37 lbs)
