Triconex | 9563-810 | Termination Panel
SKU: 9563-810

  • Manufacturer: Triconex

  • Product No.: 9563-810

  • Condition：In stock

  • Product Type: External Termination Panel

  • Product Origin: UK

  • Payment:T/T, Western Union

  • Weight: 2750g

  • Shipping port: Xiamen

  • Warranty: 12 months

Description

9563-810 Termination panel compatible with 24V digital input modules. Features 16 input points and commoned power terminals (PWR+ and PWR–). Each input is protected by a fuse with a blown-fuse indicator. Suitable for use with 32-point modules, requiring two panels per module.

Features

  • Panel Type: Commoned
  • Input Points: 16
  • Protection: Fuse with blown-fuse indicator
  • Compatibility: Requires two panels for 32-point modules
  • Labels: Comes with two sets of labels (1-16 and 17-32)

Technical Specifications

  • Leakage Current Per Point
    • Maximum: 3.3 mA
    • Typical: 2.5 mA
  • Module Compatibility
    • 3503E: 32 points, 24 VAC/VDC, commoned in groups of 8, TMR with self-test, 1A slow fuse
    • 3505E: 32 points, 24 VDC, low-threshold, commoned in groups of 8 with self-test, TMR

Key Positions

  • Small Key Position: 1
  • Large Key Position: 3

Dimensions

  • Width: 4.5 in (11.43 cm)
  • Height: 5 in (12.7 cm)
  • Depth: 4.25 in (10.795 cm)

Field Wiring Diagrams

Illustrates connections for 32-point digital input modules and the 9563-810 panel. Wiring involves connecting the module to the field using the specified termination panel.

Simplified Schematics

Shows a typical 32-point commoned digital input module with self-test, focusing on one of 32 module points.

Label Placement

  • First Panel: Labels 1-16 (front and back row)
  • Second Panel: Labels 17-32 (front and back row)
Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

Check now

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
