Schneider Electric | 140CPU11303 | Processor Module

SKU: 140CPU11303

Manufacturer: SCHNEIDER
Product No.: 140CPU11303
Condition：In stock
Product Type: Concept Processor Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

DESCRIPTION

Range of Product: Modicon Quantum automation platform
Product or Component Type: Processor
Software Name: ProWORX 32, Concept
Processor Name: 80186
Mathematical Coprocessor: Without

Complementary:

Clock Frequency: 20 MHz
Memory Description: Internal RAM 368 kB
Exact Time for 1 Kinstruction: 0.3...1.4 ms LL984
Watchdog Timer: 250 ms
Clock Drift: +/-8 s/day 32…140 °F (0…60 °C)
I/O Words:
- 30 I/32 O distributed
- 64 I/64 O max local
- 64 I/64 O remote
I/O Words/Network: 500 I/500 O distributed
Drops/Network: 63 distributed
Number of Drops: 31 remote
Number of Network: 2 remote, 3 distributed
Battery Type: Lithium, 7 µA 210 µA
Battery Capacity: 1.2 Ah
Battery Life: 10 year(s)
Number of Port: 1 Modbus RS232, 1 Modbus Plus
Communication Module Processor Capacity: 2 NOM, NOE, CR, NMS
Switch Function: Without key switch
Marking: CE
Bus Current Requirement: 790 mA
Module Format: Standard
Net Weight: 0.66 lb(US) (0.3 kg)

Environment:

Product Certifications: FM Class 1 Division 2, cUL
Standards: UL 508, CSA C22.2 No 142
Resistance to Electrostatic Discharge:
- 4 kV contact IEC 801-2
- 8 kV on air IEC 801-2
Resistance to Electromagnetic Fields: 9.14 V/m (10 V/m) 80…2000 MHz IEC 801-3
Ambient Air Temperature for Operation: 32…140 °F (0…60 °C)
Ambient Air Temperature for Storage: -40…185 °F (-40…85 °C)
Relative Humidity: 95 % without condensation
Operating Altitude: <= 16404.2 ft (5000 m)

Packing Units:

Height: 1.97 in (5 cm)
Width: 6.50 in (16.5 cm)
Length: 12.20 in (31 cm)
PWeight: 18.13 oz (514 g)
