Schneider|140CRA93200|RIO Drop Adaptor Module

SKU: 140CRA93200

Manufacturer: SCHNEIDER
Product No.: 140CRA93200
Condition：In stock
Product Type: Adaptor Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

DESCRIPTION

Schneider Modicon Quantum RIO Drop Adaptor Module Specifications

Main Specifications:

Range of product: Modicon Quantum automation platform
Product or component type: RIO drop adaptor module

Complementary Specifications:

Product compatibility: Quantum
Maximum number of I/O expansion module: 27
Type of cable: 75 Ohm coaxial cable
Transmission rate: 1544 Mbit/s
Dynamic range: 35 dB
Isolation voltage: 500 V DC coaxial center and ground
Electrical connection: 2 female connectors F, elbowed with redundant cable
Diagnostics startup: Power up and runtime
RAM address/data: Executive checksum
Power dissipation in W: 3.8 W (2 channels)
Bus current requirement: 750 mA (2 channels)
Module format: Standard

Environment:

Standards:
- UL 508
- CUL
- CSA C22.2 No 142
Resistance to electrostatic discharge:
- 4 kV contact conforming to IEC 801-2
- 8 kV on air conforming to IEC 801-2
Resistance to electromagnetic fields: 10 V/m (80…1000 MHz conforming to IEC 801-3)
Ambient air temperature for operation: 0…60 °C
Ambient air temperature for storage: -40…85 °C
Relative humidity: 95 % without condensation
Operating altitude: <= 5000 m

Packing Units:

Unit Type of Package 1: PCE
Number of Units in Package 1: 1
Package 1 Dimensions:
- Height: 5.000 cm
- Width: 16.500 cm
- Length: 31.500 cm
- Weight: 545.000 g

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
