Rockwell 1746-NIO4V Allen-Bradley Analog Combination Module

SKU: 1746-NIO4V

Manufacturer: Allen-Bradley
Product No.: 1746-NIO4V
Condition：In stock
Product Type: Analog Combination Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 630g
Shipping port: Xiamen
Warranty: 12 months

Description

The Allen-Bradley 1746-NIO4V Analog Combination Module is a versatile I/O module designed for the SLC500 system. It provides both voltage and current inputs with high resolution and two non-isolated voltage outputs.

Specifications

Model: 1746-NIO4V
Manufacturer: Rockwell Automation
Brand: Allen-Bradley
Series: SLC500
Module Type: Analog Combination Module
Inputs:
- 2 Differential Voltage / Current Inputs
- Current Input Range: -20 to 20 mA
- Current Input Resolution: 1.22070 µA per LSB
- Voltage Input Range: -10 to +10 V DC
- Voltage Input Resolution: 305.176 µV per LSB
Outputs:
- 2 Non-isolated Voltage Outputs
- Output Voltage Range: -10 to +10 V
- Output Voltage Resolution: 1.22070 mV per LSB
Backplane Current:
- 5V: 55 mA
- 24V: 115 mA
Bandwidth: 10 Hz
Update Time: 512 microseconds
Resolution: 16 bits in, 14 bits out
Step Response: 60 milliseconds in, 2.5 milliseconds out
Mounting: Rack Mount

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
