RH924YA FCP280 | Foxboro Field Control Processor

SKU: RH924YA FCP280

Manufacturer: Foxboro
Product No.: RH924YA FCP280
Condition：In stock
Product Type: Platinum Nickel Copper RTD Input Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Description

Foxboro FCP280 Field Control Processor Overview

The Foxboro FCP280 Field Control Processor is designed for versatility in distributed control systems, offering essential functionalities such as regulatory control, logic processing, timing, sequential control, data acquisition, and alarm management.

Technical Specifications

Physical Specifications:

Dimensions: 103 mm (H) x 51.5 mm (W) x 147 mm (D)
Weight: 0.6 kg (single, non-fault-tolerant module); 0.78 kg (product variant)
Fiber Optic Cabling:
- Ethernet Switch Connector: One MT-RJ connector
- FCP270 or Splitter/Combiner Connector: Two ceramic LC connectors with clip
- Cable Material: Multimode fiber (MMF) 62.5/125 µm plenum
- Cable Lengths: Available in 3 m, 15 m, 50 m, and greater than 50 m (user supplied)
- Maximum Length: 2 km

Environmental Specifications:

Operating Conditions:

Temperature: 0 to +60°C
Relative Humidity: 5 to 95% (Non-condensing)
Altitude: -300 to +3,000 m
Contamination Class: G3 (Harsh)
Vibration Resistance: 0.5 g (5 to 500 Hz)

Storage Conditions:

Temperature: -40 to +70°C
Relative Humidity: 5 to 95% (Non-condensing)
Altitude: -300 to +12,000 m

Manufacturer Information

Manufacturer: Foxboro (by Schneider Electric)
Product Number: RH924YA
Product Type: FCP280 Field Control Processor

The Foxboro FCP280 is an integral component for reliable and efficient control in various industrial applications, built to withstand challenging environments while delivering comprehensive control capabilities.

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
