PR6423/010-000 | Epro | Non-Contact Eddy Current Transducer

SKU: PR6423/010-000

Manufacturer: EPRO
Product No.: PR6423/010-000
Condition：In stock
Product Type: Non-Contact Eddy Current Transducer
Product Origin: Germany
Payment:T/T, Western Union
Weight: 120g
Shipping port: Xiamen
Warranty: 12 months

Overview

The Epro PR6423/010-000 is a non-contact Eddy Current Transducer designed for accurate measurement of static and dynamic shaft displacement. It is ideal for monitoring shaft eccentricity, vibration, and displacement in industrial machinery, adhering to international standards such as DIN 45670, ISO 10817-1, and API 670. The sensor is rated for explosive areas with Eex ib IIC T6/T4.

Technical Specifications

Measuring Range：Static: ±1.0 mm (0.04 in)
Dynamic: 0 to 500 μm (0 to 20 mil)
Best suited for: 50 to 500 μm (2 to 20 mil)
Sensitivity：8 V/mm
Target Material：Electrically conducting steel
Cylindrical shaft
Target Surface Considerations：
On measuring collars, if the target surface is less than 25 mm (0.98 in) in diameter, error may be ≥ 1%.
Error is negligible when the target surface is greater than 25 mm (0.98 in) in diameter.
Peripheral Speed of Shaft：0 to 2500 m/s
Shaft Diameter：> 25 mm (0.98 in)
Nominal Gap：1.5 mm (0.06 in) at the center of measuring range
Measuring Error After Calibration：< ±1% linearity error
Temperature Error：Zero Point: 200 mV / 100˚ K
Sensitivity: < 2% / 100˚ K
Long Term Drift：0.3% max.
Influence of Supply Voltage：< 20 mV/V
Operating Temperature Range：-35 to +180˚ C (-31 to 356˚ F)
Short-term: Up to 5 hours at +200˚ C (+392˚ F)
Storage Temperature Range：-40 to +70˚ C (-40˚ to 158˚ F)
Thread of Sensor：M10x1 or 3/8” – 24 – UNF – 2A
Sensor Material：Stainless steel
Pressure Limit：Equal for sensor and cable: 2 bar
Vibration and Shock Nominal Values at 25˚ C (77˚ F)：5 g at 60 Hz

Physical Specifications

Sleeve Thread：M10 x 1
Armored Cable：With
Sleeve Length (+9.0 mm / 0.35 in = Total Length)：25 mm (0.98 in)
Adapter Plug at 1 m (3.28 ft)：With
Total Cable Length：4 m (13.12 ft)
Cable End：Lemo connector for converter

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
