PM891K01 | ABB | Controllers - AC 800M Controllers

SKU: PM891K01

Manufacturer: ABB
Product No.: PM891K01
Condition：In stock
Product Type: Controllers - AC 800M Controllers
Product Origin: USA
Payment:T/T, Western Union
Weight: 1588g
Shipping port: Xiamen
Warranty: 12 months

General Info

Article Number: 3BSE053241R1 (PM891K01)
Redundancy: No
High Integrity: No
Clock Frequency: 450 MHz
Performance (1000 boolean operations): 0.043 ms
Performance: 0.043 ms
Memory: 256 MB
RAM Available for Application: 208.985 MB
Flash Memory for Storage: Yes

Detailed Data

Processor Type: MPC8270
Switch Over Time in Redundant Configuration: Max 10 ms
No. of Applications per Controller: 32
No. of Programs per Application: 64
No. of Diagrams per Application: 128
No. of Tasks per Controller: 32
Number of Different Cycle Times: 32
Cycle Time per Application Programs: Down to 1 ms
Flash PROM for Firmware Storage: 16 MB
Power Supply: 24 V DC (19.2-30 V DC)
Power Consumption +24 V Typ/Max: 660/750 mA
Power Dissipation: 15.8 W (18 W max)
Redundant Power Supply Status Input: Yes
Built-in Back-up Battery: No
Clock Synchronization: 1 ms between AC800M controllers by CNCP protocol
Event Queue in Controller per OPC Client: Up to 3000 events
AC 800M Transmission Speed to OPC Server: 36-86 events/sec, 113-143 data messages/sec
Communication Modules on CEX Bus: 12
Supply Current on CEX Bus: Max 2.4 A
I/O Clusters on Modulebus with Non-Redundant CPU: 0 electrical + 7 optical
I/O Clusters on Modulebus with Redundant CPU: 0 electrical + 7 optical
I/O Capacity on Modulebus: Max 84 modules
Modulebus Scan Rate: 0 - 100 ms (actual time depending on number of I/O modules)
Supply Current on Electrical Modulebus:
- 24 V: Max 1.0 A
- 5 V: Max 1.5 A
Ethernet Channels: 2
Ethernet Interface: 10/100 Mbit/s
Control Network Protocol: MMS (Manufacturing Message Service) and IAC (Inter Application Communication)
Recommended Control Network Backbone: 100 Mbit/s switched Ethernet
Real-Time Clock Stability: 50 ppm (approx 0.5h / year)
RS-232C Interface: 1 for service tool (COM 4)
RS-232C Interface (COM3) (non-redundant only): Not supported
RS-232C Interface (COM4) (non-redundant only): RS-232C, 9 600 baud, RJ-45 female (8-pole), opto isolated, no RTS-CTS support

Dimensions

Width: 174 mm (6.85 in.)
Height: 186 mm (7.32 in.)
Depth: 94 mm (3.70 in.)
Weight (Including Base): 1600 g (3.5 lbs)

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
