MVI69-MNET Modbus | Allen-Bradley ProSoft TCP/IP Communication Module

SKU: MVI69-MNET

Manufacturer: Allen-Bradley ProSoft
Product No.: MVI69-MNET
Condition：In stock
Product Type: Communication Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Description

Allen-Bradley MVI69-MNET Modbus TCP/IP Communication Module
Designed for Allen-Bradley PLC systems, this module enables seamless communication with Modbus-compatible devices.

Technical Specifications

Dimensions: Standard 1769 single-slot module
Current Load: 800 mA max @ 5 VDC
Power Supply Distance Rating: 2 (L43 and L45 installations on the first 2 slots of the 1769 bus)
Operating Temperature: 0°C to 60°C (32°F to 140°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Relative Humidity: 5% to 95% (non-condensing)
LED Indicators:
- Power and Module Status
- Application Status
- CFG Port Activity
- Ethernet Port Activity
- Error Status
CFG Port:
- RJ45 (DB-9M with supplied cable)
- RS-232 only, no hardware handshaking
App Port (Ethernet modules):
- 10/100 Base-T Ethernet compatible interface
Electrical Isolation:
- 1500 Vrms at 50 Hz to 60 Hz for 60 seconds (IEC 60950: 1991)
Ethernet Broadcast Storm Resiliency:
- ≤ 5000 [ARP] frames-per-second, ≤ 5 minutes duration
Included Cables:
- RJ45 to DB-9M cables for each port
- 6-foot RS-232 configuration cable

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
