IS200EPBPG1A| GE Fanuc| Exciter Power Backplane

SKU: IS200EPBPG1A

Manufacturer: GE Fanuc
Product No.: IS200EPBPG1A
Condition：In stock
Product Type: Exciter Power Backplane
Product Origin: USA
Payment:T/T, Western Union
Weight: 440g
Shipping port: Xiamen
Warranty: 12 months

Description

The IS200EPBPG1A is an Exciter Power Backplane designed for the EX2100 product line. It serves as the central distribution hub for power and signal connections between various exciter system modules, ensuring reliable and efficient operation of the entire exciter system. The backplane provides stable power distribution and robust communication pathways, supporting high-reliability applications in industrial control and automation.

Features

Centralized Power Distribution: Efficiently distributes power to all connected exciter modules.
Signal Interfacing: Provides secure and reliable signal connections between modules.
High Reliability: Designed for continuous operation in demanding industrial environments.
Built-in Diagnostics: Continuous self-diagnostics for fault detection and logging.
Protection Features: Includes over-voltage, over-current, and short-circuit protection.
Compact Design: Space-efficient for easy integration into existing systems.
Compliance: Meets relevant industry standards for safety and performance.

Technical Specifications

Input Voltage: 24 Vdc ±10%
Power Distribution:
- Supports multiple regulated outputs for different exciter components
- Typical output voltages: 5 Vdc, 12 Vdc, 24 Vdc
Current Rating:
- Maximum continuous current: 10 A per channel
- Peak current: 20 A (short duration)
Power Consumption: < 50 W
Temperature Range:
- Operating temperature: -40°C to +85°C
- Storage temperature: -55°C to +90°C
Humidity: 5% to 95% RH (non-condensing)
Communication Interfaces: Supports standard industrial communication protocols (e.g., RS-485, Profibus DP, EtherNet/IP)
Mounting: DIN rail or panel mount
Dimensions:
- Width: 122 mm
- Height: 92 mm
- Depth: 120 mm
Weight: 1.5 kg
Compliance:
- CE
- UL
- IECEx
- ATEX
Diagnostics: Built-in self-diagnostics for continuous monitoring and fault detection
Protection:
- Over-voltage protection
- Over-current protection
- Short-circuit protection
