IC200UEX214|GE Fanuc| 28-Point Micro PLC Expansion Unit
SKU: IC200UEX214

  • Manufacturer: GE Fanuc

  • Product No.: IC200UEX214

  • Condition：In stock

  • Product Type: 28-Point Micro PLC Expansion Unit

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 460g

  • Shipping port: Xiamen

  • Warranty: 12 months

Description

The IC200UEX214 is a 28-Point Micro PLC Expansion Unit that includes 16 digital inputs and 12 transistor outputs, all operating on 24Vdc. It is designed to expand the I/O capabilities of a base Micro PLC unit. The module can be used in various industrial automation applications to interface with sensors, switches, and control actuators or other devices.

Features

  • Inputs: Sixteen configurable DC inputs that can be used as positive or negative logic.
  • Outputs: Twelve 24Vdc transistor outputs (four low-current and eight high-current) with electronic short-circuit protection (ESCP).
  • Power Supply: Requires +24Vdc nominal input power for both the module and output circuits.
  • Compatibility: Works with any 14- to 64-point Micro PLC.
  • Distance from PLC: Can be located up to 2 meters away from the Micro PLC.
  • Terminal Strips: Equipped with removable terminal assemblies protected by hinged covers.
  • Expansion Connector: Allows for easy connection to the main PLC unit.

Technical Specifications

  • Input Voltage: 5 to 30Vdc.
  • Input Current per Input: Approximately 7.5mA.
  • Maximum Input Circuit Current: 200mA.
  • Isolation Voltage: 1500V RMS between field side and logic side, 500V RMS between groups.
  • Output Load Voltage: 24Vdc.
  • Maximum Load Current per Point (Low-Current Outputs): 0.7A.
  • Maximum Load Current per Common (Low-Current Outputs): 3.4A.
  • Maximum Load Current per Point (High-Current Outputs): 1A.
  • Maximum Load Current per Common (High-Current Outputs): 3.4A.
  • Maximum Inrush Current (Low-Current Outputs): 4A for 20ms, 1 pulse.
  • Maximum Inrush Current (High-Current Outputs): 8A for 20ms, 1 pulse.
  • Output Voltage Drop: Maximum 0.3V.
  • OFF State Leakage Current: Maximum 0.1mA.
  • Response Time: OFF to ON or ON to OFF: 0.05ms maximum at 24Vdc.
  • External Power Supply: 12/24Vdc –10%,+20%.
  • Minimum Switching Current: 10mA.
  • Fusing: Not required due to built-in ESCP. However, external fuses are recommended for load-side protection.
