HIMA | HIMATRIX F35 | Safety-Related Controller

SKU: F35

Manufacturer: HIMA
Product No.: F35
Condition：In stock
Product Type: Safety-related Controller
Product Origin: Germany
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Product Description

The technical specifications for the device:

Total Program and Data Memory: 5 MB (excluding 64 kBytes for CRCs)
Response Time: ≥ 6 ms
Ethernet Interfaces: 4 x RJ-45, 10BASE-T/100BASE-Tx with integrated switch
Fieldbus Interfaces:
- 3 x 9-pole D-sub FB1 and FB2 with fieldbus submodule pluggable
- FB3 with RS485 for Modbus (master or slave) or ComUserTask
Operating Voltage: 24 VDC, -15...+20% (rPP ≤ 15%), from a power supply unit with safe insulation in accordance with IEC 61131-2
Current Input: Max. 9 A (with maximum load), Idle: 0.5 A
Fuse (External): 10 A time-lag (T)
Buffer for Date/Time: Gold capacitor
Operating Temperature: 0...+60 °C
Storage Temperature: -40...+85 °C
Type of Protection: IP20

Protection Class:
- Ambient Temperature: 0°C to +60°C
- Protection Class: III in accordance with IEC/EN 61131-2
Storage Temperature:
- Temperature Range: -40°C to +85°C
- Pollution Degree: II in accordance with IEC/EN 61131-2
- Altitude: Up to 2000 meters
Housing Standard:
- IP Rating: IP20
Supply Voltage:
- Voltage: 24 VDC

Max. Dimensions (Without Plug):
- Width: 257 mm (with housing screws)
- Height: 114 mm (with fixing bolt)
- Depth: 97 mm (with earthing screw)
Weight: Approx. 1.2 kg
