HIMA | F2 DO 16 01 | HIMatrix | Safety-Related Controller | in Stock

SKU: F2-DO-16-01

Manufacturer: HIMA
Product No.: F2-DO-16-01
Condition：In stock
Product Type: HIMatrix Safety-Related Controller
Product Origin: Germany
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Product Description

Ethernet Interfaces:

Response Time: ≥ 20 ms
Specifications: 2 x RJ-45, 10BASE-T/100BASE-Tx with integrated switch

Power Supply:

Operating Voltage: 24 VDC, -15...+20% (rPP ≤ 15%)
Source: Power supply unit with safe insulation in accordance with IEC 61131-2
Current Input: Maximum 9 A per group
- Idle: Approximately 0.2 A per group at 24 V
Fuse (External): 10 A time-lag (T)
Back-up Battery: None

Temperature Range:

Operating Temperature: 0...+60 °C
Storage Temperature: -40...+85 °C

Protection:

Type: IP20
Dimensions (Without Plug):
- Width: 207 mm (with housing screws)
- Height: 114 mm (with fixing bolt)
- Depth: 66 mm (with earthing screw)
Weight: Approximately 0.9 kg

Digital Outputs:

Number of Outputs: 16 (non-galvanically separated)
Output Voltage: ≥ L+ minus 2 V
Output Current:
- Maximum 2 A at < 40 °C
- Maximum 1 A at 40…60 °C
Current Per Group: Maximum 8 A
Total Permissible Current: Maximum 16 A
Minimum Load: 2 mA for each channel
Lamp Load:
- Maximum 10 W (with output 1 A)
- Maximum 25 W (with output 2 A)
Inductive Load:
- Internal Voltage Drop: Maximum 1 mA at 2 V
- Maximum 500 mH at 2 V at 2 A

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
