GE | IC695LRE001| Serial Bus Transmitter Module

SKU: IC695LRE001

Manufacturer: GE Fanuc
Product No.: IC695LRE001
Condition：In stock
Product Type: Serial Bus Transmitter Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Description

The IC695LRE001 is a Serial Bus Transmitter Module for PACSystems RX3i, facilitating communication between the Universal Backplane and serial expansion or remote backplanes. It converts signal levels suitable for the Universal Backplane to those needed by Serial Expansion Backplanes.

Features

Communicates between Universal Backplane and expansion/remote backplanes.
Supports up to 500k bytes/sec data rate with remote backplanes.
Non-isolated differential communications.
Features Station Manager Port (RS-232 DCE, 1200-115200 bps).
Equipped with two green LEDs indicating module status and expansion link activity.
Suitable for Class I, Division 2, Groups A, B, C, D hazardous locations.
ATEX approved for Group 2, Category 3 applications.

Technical Specifications

Power Requirements: 5.0V, 132mA
Max Cable Length: 15m (50ft) for expansion backplanes, 213m (700ft) for remote backplanes
Effective Data Rate: 500k bytes/sec with remote backplanes
Electrical Isolation: Non-isolated
Serial Port: RS-232 DCE, 1200-115200 bps
Cable: Belden 8107, 24 AWG, 25-pin connectors
Termination: Built-in resistors for single expansion backplane systems; terminator plug IC693ACC307 for multi-backplane setups.

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
