GE Fanuc | IS210BPPCH1AD | Printed Circuit Board
SKU: IS210BPPCH1AD

  • Manufacturer: GE

  • Product No.: IS210BPPCH1AD

  • Condition：In stock

  • Product Type: Printed Circuit Board

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 2000g

  • Shipping port: Xiamen

  • Warranty: 12 months

Description

Description
The IS210BPPCH1AD is an I/O pack processor board manufactured by General Electric (GE), specifically designed for the Mark VIe turbine control system. It is one of several BPPC boards available, each with minor variations, and is not compatible with the Mark VIeS system.

Design and Construction

  • Mounting:

    • The board is factory drilled at each corner for mounting.
    • It attaches to a larger circuit board using standoffs and screw mounts.
    • Mounts are located near rounded cutouts along the long edges of the board.

  • Double-Sided Design:

    • Utilizes Surface-Mount Technology (SMT) to maximize space efficiency.
    • Features a double-sided layout for enhanced component placement.

Component Layout

  • Top Side:

    • Ethernet Ports: Two ports
    • Inductor or Choke: A small inductor or choke
    • Passive Components: Diodes, resistors, capacitors
    • Active Components: Transistors
    • Integrated Circuits: Multiple integrated circuits
    • Resistor Network Arrays: Several arrays

  • Bottom Side:

    • Primary Components: Occupied mainly by capacitors, resistors, and diodes

This detailed layout ensures the IS210BPPCH1AD board meets the high-performance requirements of the Mark VIe system while maintaining efficient use of space and robust construction.

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

Check now

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
