GE Fanuc|IC694MDL940|Relay Output Module

SKU: IC694MDL940

Manufacturer: GE Fanuc
Product No.: IC694MDL940
Condition：In stock
Product Type: Relay Output Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 2720g
Shipping port: Xiamen
Warranty: 12 months

Description

The GE Fanuc IC694MDL940 is a relay output module designed for RX3i PACSystems. It features 16 normally open Form A relays, each with a capacity of 2A per point.

Features

16 Independent Relay Outputs: Provides versatility for multiple control applications.
Normally Open Contacts: Suitable for various circuit configurations.
Compatible with RX3i Systems: Ensures seamless integration and functionality within RX3i PACSystems.

Technical Specifications

Output

Type: Relay, Form A (normally open)
Outputs per Module: 16

Electrical

Operating Voltage: 5-30 VDC, 5-250 VAC (47-63 Hz)
Output Current: 2 A per point max
Isolation: 1500 VAC between field and logic, 500 VAC between points
Minimum Load: 10 mA
Maximum Load: 2 A resistive at 250 VAC/30 VDC

Response Time

On Response Time: 15 ms max
Off Response Time: 15 ms max

Contact Life

Mechanical: 20 million operations
Electrical: 100,000 operations at 2 A

Power Consumption

At 5 VDC: 45 mA
At 24 VDC from backplane: 600 mA

Operating Conditions

Temperature: 0 to 60°C
Storage Temperature: -40 to 85°C

Physical

Weight: 0.37 kg

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
