GE Fanuc | IC694ALG223 | PACSystems RX3i Analog Input module

SKU: IC694ALG223

Manufacturer: GE Fanuc
Product No.: IC694ALG223
Condition：In stock
Product Type: PACSystems RX3i Analog Input module
Product Origin: USA
Payment:T/T, Western Union
Weight: 900g
Shipping port: Xiamen
Warranty: 12 months

Overview

The GE Fanuc IC694ALG223 is a 16-channel Analog Input Module for the PACSystems RX3i series, designed for mission-critical discrete and process applications. It offers high-speed performance, advanced diagnostics, and outstanding flexibility.

Technical Specifications

Specification	Details
Part Number	IC694ALG223
Analog Input Count & Type	16 Channel; 4-20mA; 0-20mA
Resolution & Speed	12 Bit; 13ms
Current Consumption	120mA @ 5VDC; 65mA User Supplied 24VDC
Agency Approvals	UL, UL HAZLOC
Approvals	Zone 2 CE, ATEX C1D2 ABS, BV, DNV, GL, KRS, LR
Mounting Format	On Panel/DIN Rail

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
