FBM203 B/C/D P0922UD | Foxboro Platinum Nickel Copper RTD Input Module
SKU: FBM203 B/C/D P0922UD

  • Manufacturer: Foxboro

  • Product No.: FBM203 B/C/D P0922UD

  • Condition：In stock

  • Product Type: Platinum Nickel Copper RTD Input Module

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 2000g

  • Shipping port: Xiamen

  • Warranty: 12 months

Description

Input Channels

  • Number: 8 resistance temperature detector (RTD) input channels per module
  • Isolation: Each channel is isolated and independent

Input Range (Each Channel)

  • FBM203/203d: 0 to 320 ohms (320 ohms = 64,000 counts)
    • Minimum overrange: 327.675 ohms at 65,535 counts
  • FBM203b: 0 to 640 ohms (640 ohms = 64,000 counts)
    • Minimum overrange: 655.35 ohms at 65,535 counts
  • FBM203c: 0 to 30 ohms (30 ohms = 64,000 counts)
    • Minimum overrange: 30.72 ohms at 65,535 counts

Sensor Current

  • FBM203/203d: 0.19 mA DC nominal
  • FBM203b: 0.10 mA DC nominal
  • FBM203c: 0.54 mA DC nominal

Lead Resistance

  • FBM203/FBM203b: 50 ohms maximum each lead (imbalance decreases accuracy)
  • FBM203c: 10 ohms maximum each lead (imbalance decreases accuracy)
  • FBM203d: 50 ohms maximum (imbalance does not affect accuracy)

Analog Accuracy (Includes Linearity)

  • FBM203/203d: ±0.03% of span
  • FBM203b: ±0.03% of span
  • FBM203c: ±0.1% of span

Accuracy Temperature Coefficient

  • ±50 ppm/ºC

Input Signal A/D Conversion

  • Each channel performs its own A/D signal conversion using an independent sigma-delta technique.

Integration Period

  • Software configurable

Common Mode Rejection

  • 125 dB at 50 or 60 Hz

Normal Mode Rejection

  • 95 dB at 50 or 60 Hz

Typical Resistance Temperature Sensors

  • FBM203/203d:
    • Platinum: 100 ohms nominal at 0°C
    • Nickel: 235 ohms nominal at 0°C
  • FBM203b:
    • Platinum: 200 ohms nominal at 0°C
    • Nickel: 470 ohms nominal at 0°C
  • FBM203c:
    • Copper: 10 ohms nominal at 25°C

Input Signal

  • Supports 2-, 3-, or 4-wire variable-resistance temperature sensors.
  • For 2-wire inputs, no correction for lead resistance or temperature changes.

Process I/O Communications

  • Communicates with its associated FCM or FCP via the redundant 2 Mbps module fieldbus.

Input Channel Isolation

  • Each channel is galvanically isolated from all other channels and earth (ground).
  • Withstands 600 V AC applied for one minute between any channel and ground or between channels.

Power Requirements

  • Input Voltage Range (Redundant): 24 V DC +5%, -10%
  • Consumption: 3 W (maximum)
  • Heat Dissipation: 3 W (maximum)

Operating Conditions

  • Temperature: Module: -20 to +70°C (-4 to +158°F)
  • Relative Humidity: 5 to 95% (noncondensing)
  • Altitude: -300 to +3,000 m (-1,000 to +10,000 ft)

Storage Conditions

  • Temperature: -40 to +70°C (-40 to +158°F)
  • Relative Humidity: 5 to 95% (noncondensing)
  • Altitude: -300 to +12,000 m (-1,000 to +40,000 ft)

Contamination

  • Suitable for use in Class G3 (Harsh) environments as defined in ISA Standard S71.04.

Vibration

  • 7.5 m/S² (0.75 g) from 5 to 500 Hz

Physical Specifications

  • Weight: 284 g (10 oz) approximate
  • Dimensions: 102 mm (H) x 45 mm (W) x 104 mm (D)
  • Termination Cables: Up to 30 m long, polyurethane or LSZH material
  • Construction:
    • Termination assembly material: Polyamide (PA), compression
    • Field termination connections: Compression or ring lug types
    • Dimension: 4.5 x 11 x 11.5 cm
  • Weight: 0.3 kg
