Epro | PR6424/006-030+CON021 Eddy Current Sensor with Converter

SKU: PR6424/006-030+CON021

Manufacturer: EPRO
Product No.: PR6424/006-030+CON021
Condition：In stock
Product Type: Eddy Current Sensor with Converter
Product Origin: Germany
Payment:T/T, Western Union
Weight: 220g
Shipping port: Xiamen
Warranty: 12 months

PR6424/006-030 Eddy Current Sensor

Overview

The Epro PR6424/006-030 is an Eddy Current Sensor designed for precise measurement of static and dynamic distances between a sensor head and a ferromagnetic target. It is widely used in industrial applications to monitor machinery conditions and detect potential issues early.

Technical Specifications

Dynamic Performance

Sensitivity/Linearity: 4 V/mm (101.6 mV/mil) ≤ ±1.5%
Air Gap (Center): Approx. 2.7 mm (0.11”) Nominal
Long Term Drift: < 0.3%
Range:
- Static: ±2.0 mm (0.079”)
- Dynamic: 0 to 1,000 μm (0 to 0.039”)

Target Specifications

Target/Surface Material: Ferromagnetic Steel (42 Cr Mo4 Standard)
Maximum Surface Speed: 2,500 m/s (98,425 ips)
Shaft Diameter: ≥80 mm

Environmental Specifications

Operating Temperature Range: -35 to 150°C (-31 to 302°F)
Temperature Error: <4%/100°K (API 670 Compliant)
Pressure Resistance to Sensor Head: 10,000 hPa (145 psi)
Shock and Vibration: 5g @ 60 Hz @ 25°C (77°F)

Physical Specifications

Material: Sleeve – Stainless Steel, Cable – PTFE
Weight (Sensor & 1M Cable, no Armor): ~200 grams (7.05 oz)

CON021 Eddy Current Signal Converter

Overview

The Epro CON021 is an Eddy Current Signal Converter designed to work with various Epro sensors, including PR6424/006-030. It converts the analog signals from the sensors into digital signals that can be used for monitoring and control purposes in industrial applications.

Technical Specifications

Dynamic Performance

Frequency Range (-3 dB): 0 to 20,000 Hz
Rise Time: <15 µs
Compatibility: PR6422, PR6423, PR6424/006-030, PR6425, PR6426, PR 6453
- For extended range use: CON021/91x-xxx; PR6425 always requires an extended range converter

Environmental Specifications

Operating Temperature Range: -30 to 100°C (-22 to 212°F)
Shock and Vibration: 5g @ 60 Hz @ 25°C (77°F)
Protection Class: IP20

Power & Electrical Specifications

Supply Voltage Range:
- -23V to -32V (Output Range -4V to -20V)
- -21V to -32V (Output Range -2V to -18V)

Physical Specifications

Housing Material: LMgSi 0.5 F22
Weight: ~120 grams (4.24 oz)
Mounting: 4 Screws M5x20 (Included in Delivery)
Connections:
- Transducer: Self-Locking Lemo-Plug
- Supply/Output: Screw Terminal Type (max. 1.5mm² wire)

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
