EPRO CON021+PR6423/003-130 Eddy Current Sensor with Converter

SKU: CON021+PR6423/003-130

Manufacturer: EPRO
Product No.: CON021+PR6423/003-130
Condition：In stock
Product Type: Eddy Current Sensor with Converter
Product Origin: Germany
Payment:T/T, Western Union
Weight: 220g
Shipping port: Xiamen
Warranty: 12 months

CON021 Eddy Current Signal Converter

Overview

The CON021 is a versatile eddy current signal converter designed to work with the PR642x series sensors. It offers exceptional dynamic performance measurement capabilities for various industrial applications.

Technical Specifications

Frequency Response: 0 to 20,000 Hz (-3 dB)
Response Time: <15 µs for rapid signal processing
Temperature Range: -30°C to 100°C for versatile environmental conditions
Resistance to Vibration: Withstands 5g @ 60 Hz at 25°C
Protection Class: Rated at IP20

Power Supply

Voltage: -23V to -32V (Output -4V to -20V)
Alternative Voltage: -21V to -32V (Output -2V to -18V)

Construction

Material: High-strength LMgSi 0.5 F22 alloy
Mounting Method: 4 M5x20 screws included for secure installation
Connector Type: Self-Locking Lemo-Plug for transducer; screw terminals for power/output

PR6423/003-130 Eddy Current Sensor

Overview

The PR6423/003-130 is an advanced eddy current sensor designed for high-precision measurement of shaft displacement and position in industrial machinery.

Technical Specifications

Measurement Capability: Detects radial and axial displacement
Linear Range: Measures up to 2 mm (80 mils)
Initial Air Gap: Configurable at 0.5 mm (20 mils)
Incremental Scale Factor (ISF): 8 V/mm (203.2 mV/mil) ± 5% at specified temperatures
Accuracy: Deviation from best-fit straight line (DSL) ± 0.025 mm (± 1 mil)

Target Details

Shaft Diameter: Minimum 25 mm (0.79”)
Material Compatibility: Ferromagnetic steel like 42CrMo4 (AISI/SAE 4140)

Durability

IP66 Protection: Dust-tight and protected against powerful water jets

Temperature Handling

Sensor with 1m cable: -35°C to +200°C
Cable and connector: -35°C to +150°C

Construction

Sensor Tip: Made from PEEK for robust performance
Housing: Stainless steel for corrosion resistance
Cable: PTFE for flexibility and durability
Connector: Brass with nickel plating for reliable connectivity

Weight

Approximately 100 grams (3.53 oz) including 1m cable

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
