Emerson | DeltaV | KL2101X1-BA1 | CHARM I/O Card (CIOC)

SKU: KL2101X1-BA1

Manufacturer: Delta V
Product No.: KL2101X1-BA1
Condition：In stock
Product Type: CHARM I/O Card (CIOC)
Product Origin: USA
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Hazardous Atmosphere Certifications:

II 3G Ex ec IIC Gc
- Certifications:
  - FM19ATEX0173U
  - IECEx FMG 19.0019U
  - FM21UKEX0017U
  - CL. I Div. 2 GP. A,B,C,D
  - CL. I Zone 2 AEx/Ex ec IIC Gc
  - FM17CA0145U
  - FM17US0286U

Power Specifications:

Input Power:
- 24 VDC at 2 A
Output Power:
- 6.3 VDC at 3.25 A

Environmental Specifications:

Ambient Temperature:
- Operating: -40 °C to +70 °C
Shock:
- 10g half-sine wave for 11 msec
Vibration:
- 1mm peak to peak from 2 to 13.2Hz; 0.7g from 13.2 to 150Hz
Airborne Contaminants:
- ISA-S71.04 –1985 Airborne Contaminants Class G3
Relative Humidity:
- 5 to 95% non-condensing

Installation and Safety Notes:

Installation Instructions:
- Refer to document 12P5403 "DeltaV™ Electronic Marshalling Digital Automation System (CHARM I/O Subsystem) Zone 2 Installation Instructions" for specific guidelines on installation, removal, and operation in hazardous areas.
- Additional installation instructions are available in the "DeltaV™ S-Series and CHARMs Hardware Installation" manual.
Removal and Insertion:
- Cannot be removed or inserted with system power energized unless the area is confirmed to be non-hazardous.
- Safety precautions must be followed to ensure proper handling and operation in hazardous environments.

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
