EMERSON | DeltaV | KJ3223X1-BA1 | AI 16 CH 4-20mA HART Card

SKU: KJ3223X1-BA1

Manufacturer: Emerson
Product No.: KJ3223X1-BA1
Condition：In stock
Product Type: AI 16 CH 4-20mA HART CARD
Product Origin: USA
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

DESCRIPTION

Emerson KJ3223X1-BA1 AI 16 CH 4-20mA HART Card, Series 2

Certifications:
- II 3 G Ex nA [ic] IIC Gc
- II 3 G Ex nA [nL] IIC Gc
- FM13ATEX0034U
- IECEx FMG 13.0015U
Power Specifications:
- Local Bus Power: 12 VDC at 150 mA
- Bussed Field Power: 12 VDC at 600 mA
- Field Circuit: 24 VDC at 32 mA per channel
Environmental Specifications:
- Ambient Temperature: -40°C to +70°C
- Shock: 10 g half-sine wave for 11 ms
- Vibration: 1 mm peak to peak from 2 to 13.2 Hz; 0.7 g from 13.2 to 150 Hz
- Airborne Contaminants: Class G3 (ISA-S71.04 –1985)
- Relative Humidity: 5% to 95% Non-Condensing
- Terminal Block Key Position: A2
Installation and Safety Requirements:
- Field power must be removed before connecting or removing the device.
- An I/O loop assessment is required for all energy-limited nodes.
- The unit cannot be removed or inserted with system power energized.
- Non-sparking field circuits must be de-energized before any removal or insertion, including the fused terminal block.
- A rotary keying system ensures compatibility between I/O cards and terminal blocks after installation.
