Emerson | Delta V | KJ1501X1-BK1 | DC/DC System Power Supply

SKU: KJ1501X1-BK1

Manufacturer: Emerson
Product No.: KJ1501X1-BK1
Condition：In stock
Product Type: Power Supply Unit
Product Origin: Germany
Payment:T/T, Western Union
Weight: 4000g
Shipping port: Xiamen
Warranty: 12 months

Technical Specifications:

Hazardous Atmosphere Certification:

Certification: II 3 G
Nemko No.: 07ATEX3058U
Classification: Ex nA nC IIC T4

Alarm Relay Field Circuit Parameters:

Vmax (Maximum Voltage): 30 VDC
Imax (Maximum Current): 135 mA
Li: 0 (Inductance)
Ci: 0 (Capacitance)

System Power:

Input Power: Not specified in the provided details.
Output Power:
- Output Voltage Range: 19.2 VDC to 28.8 VDC
- Total Output Power: 10.2 W at 70°C (combined outputs of 5 VDC and 3.3 VDC)
Specific Output Conditions:
- 12 VDC at 8 A max up to 60°C or 6 A max up to 70°C
- 5.1 VDC at 2.0 A
- 3.4 VDC at 2.0 A

Environmental Specifications:

Ambient Temperature: -40°C to 70°C
Shock: 10g, ½ Sinewave for 11 msec
Vibration:
- 1mm Peak to Peak from 5 to 16Hz
- 0.5g from 16 to 150Hz
Airborne Contaminants: ISA-S71.04 –1985 Airborne Contaminants Class G3
Relative Humidity: 5% to 95% Non-Condensing

Key Features:

Certifications: Suitable for hazardous environments with specified explosive gas atmospheres.
Power Output: Provides multiple DC voltage outputs with varying current capacities.
Environmental Durability: Designed to operate in harsh conditions, including wide temperature ranges, shock, vibration, and airborne contaminant resistance
