Bently Nevada | 991-06-50-01-00 | Thrust Transmitter
SKU: 991-06-50-01-00

  • Manufacturer: BENTLY NEVADA

  • Product No.: 991-06-50-01-00

  • Condition：In stock

  • Product Type: Thrust Transmitter

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 820g

  • Shipping port: Xiamen

  • Warranty: 12 months

The 991-06-50-01-00 Thrust Transmitter provides a 4-20 mA signal proportional to thrust position, ideal for monitoring shaft axial displacement. It is a 2-wire, loop-powered device designed to accept inputs from the 3300 NSv proximity probe and its matching extension cable. The transmitter conditions these inputs into appropriate engineering units for accurate axial position readings.

Specifications:

  • Full Scale: -0.6 to 0.6 mm
  • Sensitivity: 0.0001 mm/V
  • Linearity: ±0.02% of full scale
  • Output: 4 to 20 mA
  • Power Supply: 12 to 36 VDC
  • Ambient Temperature: -40 to 85°C
  • Humidity: 0 to 100% RH (non-condensing)

Features:

  • Integrated Proximitor Sensor: No external unit required, simplifying installation.
  • Diagnostic Outputs: Non-isolated "PROX OUT" and "COM" terminals, plus a coaxial connector, provide a dynamic vibration and gap voltage signal for diagnostics.
  • Adjustable Potentiometers: Non-interacting zero and span potentiometers allow easy loop adjustments.
  • Test Input Pin: Enables quick verification of the loop signal using a variable DC voltage source.
  • Power-up Inhibit Circuit: Prevents signal errors during power line transients.
  • Signal Defeat Circuit: Inhibits high outputs or false alarms from faulty probes or loose connections.
  • Mounting Options: Comes with DIN-rail clips or bulkhead mounting screws for easy installation.
  • Potted Construction: Designed for environments with high humidity (up to 100% condensing)
