Bently Nevada | 3500/25 125792-01 | Enhanced Keyphasor Module
SKU: 125792-01

  • Manufacturer: BENTLY NEVADA

  • Product No.: 125792-01

  • Condition：In stock

  • Product Type: Enhanced Keyphasor Module

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 2000g

  • Shipping port: Xiamen

  • Warranty: 12 months

Product Description

The 125792-01 is an Enhanced Keyphasor Module developed by Bently Nevada, designed for use within the 3500 system. This module is integral for precise timing measurements related to shaft rotative speed and vector parameters such as 1X vibration amplitude and phase. It is a half-height, two-channel module that ensures accurate monitoring and control of machinery.

Key Specifications:

  • Inputs: Receives signals from proximity probes or magnetic pickups.
  • Keyphasor Signals: Provides precise indications of the alignment of the Keyphasor mark on the shaft with the transducer.
  • Power Consumption: Typically 3.2 Watts.
  • Speed/Frequency Signal Accuracy: ±0.05%.
  • Speed/Frequency Signal Resolution: 0.1 RPM.
  • Sampling Rate: 1000 Hz.
  • Output Signal: 4-20mA.
  • Operating Temperature Range: -40°C to +85°C.
  • Humidity Range: 0 to 100% RH.
  • Dimensions: 119.9 mm x 24.4 mm x 256.5 mm (4.72 in x 0.96 in x 10.10 in).
  • Weight: 0.34 kg (0.76 lbs).
Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

Check now

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
