Allen-Bradley|SSt-ESR2-CLX|CLX-500/XMLSchema Module

SKU: SSt-ESR2-CLX

Manufacturer: Allen-Bradley
Product No.: SSt-ESR2-CLX
Condition：In stock
Product Type: CLX-500/XMLSchema Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 1g
Shipping port: Xiamen
Warranty: 12 months

Description

The SST-ESR2-CLX-RLL is a CLX-500/XMLSchema module designed for Ethernet and serial networks, featuring robust processing and memory capabilities to handle complex industrial automation tasks.

Features

Processor: Freescale PPC processor
Memory: 16 MB local FPGA RAM, 124 MB onboard PPC memory
Storage: 8 MB sectored flash memory, 2 MB serial flash memory
Interface: 248 words of input/output data, 250 words of status data
Database Access: Direct access to 30720 words via backplane AOI

Technical Specifications

Memory and Storage:
- 16 MB local FPGA RAM
- 124 MB onboard PPC memory
- 8 MB sectored flash memory for program/configuration
- 2 MB serial flash memory for FPGA program/configuration
CLX Interface:
- 248 words of Output data
- 248 words of Input data
- 250 words of Status data
Environmental:
- Storage temperature: -40°C to 85°C
- Operating temperature: 0°C to 60°C
- Operating RH level: 5% to 95%, non-condensing
- Pollution Degree: 1 (no pollution or only non-conductive/non-corrosive)
Backplane Current Consumption:
- 850 mA @ 5 VDC
- 1.75 mA @ 24 VDC
MTBF: 56 years (Telecordia SR332, Issue 1)

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
