Allen-Bradley|1785-L20E| Ethernet PLC-5 programmable controller

SKU: 1785-L20E

Manufacturer: Allen-Bradley
Product No.: 1785-L20E
Condition：In stock
Product Type: Ethernet PLC-5 programmable controller
Product Origin: USA
Payment:T/T, Western Union
Weight: 1g
Shipping port: Xiamen
Warranty: 12 months

Description

The 1785-L20E is an Ethernet PLC-5 programmable controller designed for industrial automation, offering reliable performance with integrated communication capabilities and flexible I/O configurations.

Features

Integrated Communication: Supports Ethernet and Data Highway Plus (DH+).
Flexible I/O: Manages up to 512 mixed I/O points or 512 inputs/outputs complement.
Compact Design: Suitable for various industrial applications.

Technical Specifications

User Memory: 16k words
I/O Capacity:
- Up to 512 mixed I/O points
- Or 512 inputs and outputs complement
Communication Ports:
- 1 Ethernet port
- 1 DH+ port
Channels:
- Maximum of 13 channels
- 0 local chassis
- 12 remote chassis
Power Requirements:
- Power dissipation: Up to 19W
- Backplane current load: 3.6A at 5V DC
Operating Temperature: 0 to 60°C (32 to 140°F)
Non-operating Temperature: -40 to 85°C (-40 to 185°F)
Relative Humidity: 5% to 95% non-condensing
Battery:
- Type: 1770-XYC containing 0.65 grams of lithium
- Power-off duration at 60°C: Approximately 84 days when BATT LED first lights
Certifications: UL, CSA, CE, C-Tick

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
