ADV859-P00 | Yokogawa | Digital I/O Module

SKU: ADV859-P00

Manufacturer: Yokogawa
Product No.: ADV859-P00
Condition：In stock
Product Type: Digital I/O Module
Product Origin: Japan
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Product Description

The technical specification of ADV859:

Number of I/O Channels: 16-channel input, 16-channel output.
Signal Isolation: Isolated channels.
Input Signal:
- Contact Input:
  - OFF Signal: 100 kΩ or more.
  - ON Signal: 200 Ω or less.
  - Minimum Current for Short-Circuited Contact: 1.25 mA.
- Voltage Input:
  - OFF Signal: 4.5 to 25 V DC.
  - ON Signal: ±1 V DC, 200 Ω or less.
Input Contact Rating: 5 V DC, 20 mA or more.
Pushbutton Input Function: Not supported.
Input Response Time: 8 ms (for status input).
Output Signal: Transistor contact.
Output Contact Rating: Inductive load, resistive load: 30 V DC, 100 mA.
Output Response Time: 16 ms or less.
Pulse Width: 8 ms to 7200 s.
Pulse Width Resolution: 8 ms, with a maximum 1 ms addition for ON/OFF delay time.
Maximum Current Consumption: 450 mA (5 V DC).
Weight: Approx. 0.30 kg.
External Connection: Dedicated cable (KS2).
Compatible Card: ST2 compatible.

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
