ABB PM858K01 Controller - AC 800M Controller

SKU: PM858K01

Manufacturer: ABB
Product No.: PM858K01
Condition：In stock
Product Type: Controllers - AC 800M Controller
Product Origin: USA
Payment:T/T, Western Union
Weight: 1179g
Shipping port: Xiamen
Warranty: 12 months

General Information

Article Number: 3BSE082895R1 (PM858K01)
Redundancy: No
High Integrity: No
Clock Frequency: 33 MHz
Performance, 1000 Boolean Operations: 0.36 ms
Performance: 0.36 ms
Memory: 16 MB
RAM Available for Application: 7.147 MB
Flash Memory for Storage: Yes

Environment and Certification

Temperature, Operating: +5 to +55 °C (+41 to +131 °F)
Temperature, Storage: -40 to +70 °C (-40 to +158 °F)
Temperature Changes: 3 °C/minute according to IEC/EN 61131-2
Pollution Degree: Degree 2 according to IEC/EN 61131-2
Corrosion Protection: G3 compliant to ISA 71.04
Relative Humidity: 5 to 95 %, non-condensing
Emitted Noise: < 55 dB (A)
Vibration:
- 10 < f < 50 Hz: 0.0375 mm amplitude
- 50 < f < 150 Hz: 0.5 g acceleration
- 5 < f < 500 Hz: 0.2 g acceleration
Rated Isolation Voltage: 500 V a.c.
Dielectric Test Voltage: 50 V
Protection Class: IP20 according to EN 60529, IEC 529
Altitude: 2000 m according to IEC/EN 61131-2
Emission & Immunity: EN 61000-6-4, EN 61000-6-2
Environmental Conditions: Industrial
CE Mark: Yes
Electrical Safety: EN 50178, IEC 61131-2, UL 61010-1, UL 61010-2-201
Hazardous Location: cULus Class 1, Zone 2, AEx nA IIC T4, ExnA IIC T4Gc X
ISA Secure Certified: Yes
Marine Certificates: DNV-GL
TUV Approval: No
RoHS Compliance: EN 50581:2012
WEEE Compliance: DIRECTIVE/2012/19/EU

Dimensions

Width: 119 mm (4.7 in.)
Height: 186 mm (7.3 in.)
Depth: 135 mm (5.3 in.)
Weight (Including Base): 1200 g (2.6 lbs)
