ABB|3BSE018168R1|PM851K01 Processor Unit Kit

SKU: 3BSE018168R1 PM851K01

Manufacturer: ABB
Product No.: 3BSE018168R1 PM851K01
Condition：In stock
Product Type: Processor Unit Kit
Product Origin: Switzerland
Payment:T/T, Western Union
Weight: 780g
Shipping port: Xiamen
Warranty: 12 months

Specifications

Description	Details
Manufacturer	ABB
Model	PM851K01
Ordering Information	3BSE018168R1
Catalog	800xA
Origin	Sweden (SE), Germany (DE)
HS Code	85389091
Dimensions	16 cm x 16 cm x 12 cm
Weight	0.8 kg
Medium Description	24 MHz and 12 MB

Package Includes

PM851A, CPU
TP830, Baseplate
TB850, CEX-bus terminator
TB807, ModuleBus terminator
Battery for memory backup (4943013-6)
No license included

Technical Information

The PM851K01 Processor Unit Kit includes:

PM851, CPU
TP830, Baseplate (width = 115 mm)
TB850, CEX-bus terminator
TB807, ModuleBus terminator
Battery for memory backup (4943013-6)

The CPU board contains a microprocessor, RAM memory, a real-time clock, LED indicators, an INIT push button, and a CompactFlash interface. The base plate of the PM851A controller has two RJ45 Ethernet ports (CN1, CN2) for connection to the Control Network, and two RJ45 serial ports (COM3, COM4). Note that a PM851/PM851A is restricted to one Ethernet (CN1) port, thus redundant Ethernet is not available. One serial port (COM3) is an RS-232C port with modem control signals, while the other port (COM4) is isolated for configuration tool connection.

Features and Benefits

Reliability: Simple fault diagnosis procedures.
Modularity: Allows for step-by-step expansion.
Protection: IP20 Class protection without the need for enclosures.
Configuration: Can be configured with 800xA control builder.
Certification: Full EMC certification.
Communication: Hardware based on standards for optimum communication connectivity (Ethernet, PROFIBUS DP, etc.).
