991-01-XX-01-00 | Bently Nevada | Thrust Transmitter

SKU: 991-01-XX-01-00

Manufacturer: BENTLY NEVADA
Product No.: 991-01-XX-01-00
Condition：In stock
Product Type: Thrust Transmitter
Product Origin: USA
Payment:T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months

Overview

The Bently Nevada 991-01-XX-01-00 is a Thrust Transmitter designed for monitoring axial displacement in machinery. It is commonly used in applications such as centrifugal air compressors, small pumps, motors, and fans.

Technical Specifications

Manufacturer: Bently Nevada
Product No.: 991-01-XX-01-00
Product Type: Thrust Transmitter
Input Signal: 3300 NSv proximity probe
Output Signal: 4 to 20 mA proportional to axial displacement
System Length Options: 5 meters and 7 meters
Mounting Options: DIN-rail clips or bulkhead mounting screws
Operating Temperature Range: -18°C to +71°C (-0°F to +160°F)
Power Supply: 24 VDC
Weight: 1 kg (2.2 lbs)

Features

Integrated Proximitor Sensor: No external unit required.
Non-isolated Terminals: Provides dynamic vibration and gap voltage signal output for diagnostics.
Loop Adjustment: Non-interacting zero and span potentiometers under the Transmitter label.
Power-up Inhibit Circuit: Eliminates signal errors due to line voltage transients.
Not OK/Signal Defeat Circuit: Prevents high outputs or false alarms due to a faulty proximity probe or loose connection.
Potted Construction: Suitable for high humidity environments (up to 100% condensing).
