140DDI35310 | SCHNEIDER | Modicon Quantum Discrete Input Module

SKU: 140DDI35310

Manufacturer: SCHNEIDER
Product No.: 140DDI35310
Condition：In stock
Product Type: Discrete Input Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 300g
Shipping port: Xiamen
Warranty: 12 months

Overview

The 140DDI35310 is a Discrete Input Module for the Modicon Quantum automation platform by Schneider Electric. It features 32 low-voltage DC discrete inputs, designed for high-performance applications requiring reliable input signal detection in industrial environments.

Specifications

Product Type: Low Voltage DC Discrete Input Module
Platform: Modicon Quantum Automation
Discrete Inputs: 32
Input Voltage: 24 V DC
Voltage Limits: 19.2...30 V
State 1 Voltage: -30...-15 V DC
State 0 Voltage: -5...0 V DC
State 1 Current: ≥ 2.5 mA at Us = -14 V
State 0 Current: ≤ 0.5 mA
Input Impedance: 2400 Ω

Performance & Protection

Response Time: ≤ 1 ms (both state 0 to state 1 and vice versa)
Maximum Input: 30 V continuous, 50 V for 1 ms decaying pulse
Leakage Current: 200 mA at Us = 5.5 V and Uin = 4 V
Protection: Input protection by resistor
Power Dissipation: 1.5 W + (0.26 x number of points on)

Isolation & Signaling

Bus Isolation: 1780 Vrms for 1 minute
Group Isolation: 500 Vrms for 1 minute
Local Signaling:
- 1 LED (green) for bus communication (Active)
- 1 LED (red) for external fault detected
- 32 LEDs (green) for input status

Electrical & Physical Details

Bus Current Requirement: 330 mA
Module Format: Standard
Net Weight: 0.3 kg (0.66 lbs)

Environmental Conditions

Operating Temperature: 0...60°C (32...140°F)
Storage Temperature: -40...85°C (-40...185°F)
Humidity: 95% without condensation
Altitude: ≤ 5000 m

Compliance & Safety

Certifications:
- UL 508
- CSA C22.2 No 142
- RINA
- GOST
- FM Class 1 Division 2
- C-Tick
- RMRS
Electrostatic Discharge: 4 kV contact, 8 kV air (IEC 801-2)
Electromagnetic Resistance: 10 V/m, 80...2000 MHz (IEC 801-3)
