140CPS11100 | SCHNEIDER | Power Supply Module

SKU: 140CPS11100

Manufacturer: SCHNEIDER
Product No.: 140CPS11100
Condition：In stock
Product Type: Power Supply Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 650g
Shipping port: Xiamen
Warranty: 12 months

Main

Range of product: Modicon Quantum automation platform
Product or component type: Power supply module
Power supply type: Standalone

Complementary

Input voltage: 120...230 V AC, 100...276 V, 47...63 Hz
Input current:
- 200 mA (230 V)
- 400 mA (115 V)
Inrush current:
- 10 A (230 V)
- 20 A (115 V)
Rated power in VA: 50 VA
Associated fuse rating: 1.5 A slow-blow
Harmonic distortion: ≤ 10 % of fundamental rms value
Output voltage: 5.1 V DC
Power supply output current: 3 A (standalone)
Output overvoltage protection: Internal
Output overload protection: Internal
Power dissipation: 2 + (3 x Iout) where Iout is in A
Local signalling: 1 LED (green power PWR OK)
Marking: CE
Module format: Standard
Product weight: 0.65 kg

Environment

Standards: CSA C22.2 No 142, UL 508
Product certifications: CUL, FM Class 1 Division 2
Resistance to electrostatic discharge:
- 4 kV contact conforming to IEC 801-2
- 8 kV on air conforming to IEC 801-2
Resistance to electromagnetic fields: 10 V/m (80...2000 MHz conforming to IEC 801-3)
Ambient air temperature for operation: 0...60 °C
Ambient air temperature for storage: -40...85 °C
Relative humidity: 95 % without condensation
Operating altitude: ≤ 5000 m
