140AVI03000 | SCHNEIDER | Analog Input Module

SKU: 140AVI03000

Manufacturer: SCHNEIDER
Product No.: 140AVI03000
Condition：In stock
Product Type: Analog Input Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

DESCRIPTION

Schneider Electric 140AVI03000 Analog Input Module Overview
- Type: Analog input module
- Channels: 8 analog input channels
- Resolution: 16-bit
- Compatibility: Modicon Quantum platform; integrates with ProWORX 32 and Unity Pro
Technical Specifications
- Input Type: Differential
- Addressing Requirement: 9 input words
Analog Input Types
- Bipolar current: 20 mA
- Bipolar voltage: ±10 V
- Bipolar voltage: ±5 V
- Unipolar current: 0-20 mA
- Unipolar voltage: 0-10 V
- Unipolar voltage: 0-5 V
Performance Metrics
- Analog Input Resolution: 16 bits
- Linear Measuring Range: (input range) x 1.024 mA or (input range) x 1.024 V
- Absolute Maximum Input: 50 V DC, 25 mA
- Input Impedance: > 20 ohms (voltage), 250 MΩ ± 0.03%
- Absolute Accuracy Error: ± 0.03% or ± 0.05% of full scale maximum
- Linearity Error: ± 0.008%
- Accuracy Drift: ± 0.0015% of full scale/°C or ≤ 0.004% of full scale/°C
- Common Mode Rejection: > -80 dB at 60 Hz
Isolation
- 500 Vrms AC for 60 seconds between channels and bus
- 750 V DC between channels
- Update Time: 10 ms
Fault Types
- Broken wire (4-20 mA)
- Overtacking scale (1-5 V)
Local Signaling
- 1 green LED (bus communication)
- 1 red LED (external fault)
- 8 green LEDs (channel status)
- 8 red LEDs (channel fault)
Electrical Requirements
- Bus Current Requirement: 280 mA
- Power Dissipation: 2.2 W
- Module Format: Standard
Physical Specifications
- Net Weight: 0.7 lb (0.3 kg)
- Operating Temperature: 0-60 °C
- Storage Temperature: -40-85 °C
- Relative Humidity: 95% without condensation
- Operating Altitude: ≤ 5000 m
Certifications
- UL 508
- CSA C22.2 No 142
- FM Class 1 Division 2
- cUL
Environmental Resistance
- IEC 801-2 (electrostatic discharge)
- IEC 801-3 (electromagnetic fields)

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
