Honeywell |8C-SHEDA1|Series 8 Header Board

SKU: 8C-SHEDA1

Manufacturer: Honeywell
Product No.: 8C-SHEDA1
Condition：In stock
Product Type: Series 8 Header Board
Product Origin: USA
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Description

The 8C-SHEDA1 Header Board is used to distribute 24 VDC power and IO-Link communication throughout the cabinet. It provides power to one or more columns of mounting plates on either side of the cabinet that contains the power system. The IOTA receives its power and IO-Link communication through a combination power/IO-Link cable from the header board.

Features

Redundant power distribution and IO-Link communication.
Extend power and IO-Link to adjacent cabinets via connectors.
Four connectors for combination power/IO-Link cables.
Daisy-chained cable connections allow multiple IO modules without affecting others if one is disconnected.

Technical Specifications

Power Input/Output: 24 VDC
Power Connectors: 3
Combo Cable Connectors: 4 pairs, 6 pins each
IO-Link Extension: 2 pairs, 3 pins each
Ambient Temperature Range: 0 to 60°C
Redundant Power and IO Communication: Supported
Power Distribution: Can provide redundant power and IO communication
Connector Pairs: 4 for combination power/IO-Link cable to IO modules in the cabinet
Daisy-Chaining: Combination power/IO-Link cable can be daisy-chained to connect multiple IO modules

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
