Allen-Bradley|MPL-B4530F-MJ72AA|Low-Inertia Brushless Servo Motor

SKU: MPL-B4530F-MJ72AA

Manufacturer: Allen-Bradley
Product No.: MPL-B4530F-MJ72AA
Condition：In stock
Product Type: Low-Inertia Brushless Servo Motor
Product Origin: USA
Payment:T/T, Western Union
Weight: 1g
Shipping port: Xiamen
Warranty: 12 months

Description

The Allen Bradley MPL-B4530F-MJ72AA is a low-inertia brushless servo motor from the MP Series, designed for high-performance industrial applications. It operates at 480V AC and features a keyed shaft extension with a speed rating of 3000 RPM. This motor does not include a brake option.

Features

High-resolution multi-turn encoder (absolute feedback)
Keyed shaft extension for secure coupling
SpeedTEC DIN connector with 180° rotatable quick connect
No brake option
Free mounting holes (Type FF)

Technical Specifications

General:

Voltage: 460 V AC
Frame Size: 45 = 130 mm (5.12 in.)
Speed Rating: 3000 RPM
Magnet Stack Length: 30 = 76.2 mm (3.0 in.)
Armature Voltage: 460 V

Feedback:

Encoder Type: Multi-turn high-resolution encoder (absolute feedback)

Enclosure:

Shaft Extension: Keyed
Mounting Holes: Free mounting holes (Type FF)

Connectors:

Connector Type: SpeedTEC DIN Connector, Right Angle
Rotatability: 180° Rotatable (Quick Connect)

Brake Option:

Brake: No Brake

Environmental:

Enclosure: IEC Metric

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
