Allen-Bradley|2711P-B7C22D9P|PanelView Plus 7 Performance Terminal

SKU: 2711P-B7C22D9P

Manufacturer: Allen-Bradley
Product No.: 2711P-B7C22D9P
Condition：In stock
Product Type: PanelView Plus 7 Performance Terminal
Product Origin: USA
Payment:T/T, Western Union
Weight: 2300g
Shipping port: Xiamen
Warranty: 12 months

Overview
Operator panel with a 7-inch TFT color display, featuring resistive touchscreen and keypad options. Supports dual-port Ethernet and EtherNet/IP protocol.

Key Features

Display: 640x480 pixels, 300 cd/m² brightness, LED backlight (50,000-hour lifespan).
Connectivity: Dual-port Ethernet (10/100 Mbps), USB Host/Device ports.
Memory: 1GB RAM, 512MB non-volatile memory, SD/MMC card slot.

Technical Specifications

Power Supply: 18-30V DC, max 50W consumption.
Dimensions: 285mm (W) x 179mm (H) x 69.6mm (D).
Weight: 1.47kg.
Operating Temperature: -25°C to 55°C.
Storage Temperature: -25°C to 70°C.
IP Rating: IP66 (front).
Shock/Vibration: 15g shock, 500Hz vibration.
OS: Windows CE 6.0.

Compliance
Certified for AS/NZS CISPR 11, EN 61000-6-2/4, UL 50, CE, CSA, RoHS, and more.

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
