Allen-Bradley|1756-OW16I|ControlLogix isolated Contact Output Module

SKU: 1756-OW16I

Manufacturer: Allen-Bradley
Product No.: 1756-OW16I
Condition：In stock
Product Type: ControlLogix isolated Contact Output Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Description

The Allen-Bradley 1756-OW16I is a ControlLogix isolated contact output module, designed for AC (10–240V) and DC (5–125V) applications.

Features

Provides 16 individually isolated Normally Open (N.O.) outputs.
Supports pilot duty ratings of C300/R150.
Ensures low initial contact resistance (≤100 mΩ @ 6V 1A).

Technical Specifications

Operating voltage: 5–125V DC, 10–240V AC.
Output current: 1A @ 5–30V DC, 0.75A @ 240V AC.
Output delay: ≤10 ms (Off to On/On to Off).
Current draw: 150 mA @ 5.1V, 150 mA @ 24V.
Power dissipation: 4.5 W max @ 60°C.
Thermal dissipation: 15.35 BTU/hr.

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
