Allen-Bradley|1734-OB8E|POINT I/O Digital DC Output Module

SKU: 1734-OB8E

Manufacturer: Allen-Bradley
Product No.: 1734-OB8E
Condition：In stock
Product Type: POINT I/O Digital DC Output Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 432g
Shipping port: Xiamen
Warranty: 12 months

Description

The Allen-Bradley 1734-OB8E is a POINT I/O digital DC output module designed for electronically protected sourcing outputs in industrial automation systems

Features

Compact design with eight outputs
Electronically fused for short-circuit protection
Compatible with POINT I/O systems

Technical Specifications

Output Voltage Range

10-28.8V DC

Nominal Voltage

24V DC

On-State Voltage Drop

0.2V DC max

On-State Current

1.0 mA min per channel 3.0 A max per module

Off-State Leakage Current

0.5 mA max

Surge Current

2 A for 10 ms repeatable every 3 s

POINT Bus Current

75 mA at 5V DC

Power Dissipation

2.0 W max at 28.8V DC

Thermal Dissipation

6.8 BTU/hr max at 28.8V DC

Output Delay Time

0.1 ms off to on 0.1 ms on to off

Short Circuit Current

7 A typical electronically limited

Operating Temperature

-20°C to 55°C

Storage Temperature

-40°C to 85°C

Dimensions

56.0 x 12.0 x 75.5 mm

Weight

33 g

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
