Yokogawa|ATSA3S-0|Analog Input Module
SKU: ATSA3S-0

  • Manufacturer: Yokogawa

  • Product No.: ATSA3S-0

  • Condition：In stock

  • Product Type: Analog Input Module

  • Product Origin: Japan

  • Payment:T/T, Western Union

  • Weight: 300g

  • Shipping port: Xiamen

  • Warranty: 12 months

Description

The ATSA3S-0 is an Analog Input Module with Built-In Barrier designed for 4 to 20 mA signals, featuring 8 isolated channels. It supports HART communication and integrates seamlessly into Field Control Stations (FCS) for process control applications.

Features

  • Supports 4 to 20 mA input signals.
  • 8 isolated channels.
  • Built-in barrier for intrinsic safety.
  • HART communication capability.
  • Easy connection via pressure clamp terminal block.

Technical Specifications

  • Operating Voltage: 125 Vdc nominal.
  • Power Consumption: Less than 6 W under normal conditions.
  • Communication Interfaces: Isolated RS485, IRIG-B, 100 Mb Ethernet.
  • Timing Accuracy: Better than 1 ms.
  • Temperature Range: -20°C to +70°C.
  • Humidity Range: Up to 95% non-condensing.
  • Dimensions: 130 mm x 94 mm x 32.8 mm.
  • Weight: Approximately 0.3 kg.
  • Number of Digital Inputs: 24.
  • Number of Digital Outputs: 16.
  • Sampling Rate: 4 kHz per channel.
  • Analog Inputs: 16 channels.
  • Withstanding Voltage: 1500 V AC.
  • Input Resistance: 1 MΩ or larger.
  • Accuracy: ±16 µA.
  • Step Response Time: 100 ms.
  • Data Update Period: 10 ms.
  • Transmitter Power Supply: 16 V DC or higher (output current limit: 20 mA).
  • Maximum Current Consumption: 150 mA (5 V DC), 450 mA (24 V DC).
