YAMATAKE|EST0240Z05WBX00|Medium-Size Programmable Display Unit

SKU: EST0240Z05WBX00

Manufacturer: YAMATAKE
Product No.: EST0240Z05WBX00
Condition：In stock
Product Type: Medium-Size Programmable Display Unit
Product Origin: Germany
Payment:T/T, Western Union
Weight: 50g
Shipping port: Xiamen
Warranty: 12 months

Description

The Yamatake EST0240Z05WBX00 is a medium-size programmable display unit featuring a high-visibility STN color LCD with 256-color display and BMP bitmap support. It is designed for industrial applications requiring multi-window displays and user-friendly interface creation tools.

Features

High-visibility STN color LCD
256-color display with BMP support
Multi-window display capability
Easy application creation with AP Editor (Windows 95/98 compatible)
Serial and infrared (IrDA) communication ports

Technical Specifications

Display Unit

Resolution: 320 x 240 pixels
Bit pitch: 0.10 (W) x 0.36 (H)
Display life: Approximately 30,000 hours
Backlight life: 10,000 hours (luminosity expected to halve)

Character Display

Types: ANK 158 types, KANJI 6349 types (including Non-KANJI 453 characters)
Maximum characters: 40 characters x 30 lines (8 x 8 bits), 40 characters x 15 lines (8 x 16 bits), 20 characters x 15 lines (16 x 16 bits)

Memory and Panels

Memory capacity: 1 MB
Registered screens: Up to 999 panels
Simultaneous panel display: Up to 8 panels

Touch Interface

Method: Transparent resistance film method (Analog)
Life: 1 million cycles by finger inputting

Communication Interfaces

Serial: RS-232C, RS-485 (full/half duplex)
Infrared: IrDA 1.0 equivalent

Power Supply

Voltage: 24Vdc ± 15% (20.4 to 27.6V)
Ambient temperature: 0 to 50°C
Humidity: 30 to 85% (no condensation)

Environmental Protection

Rating: IP65 (dust and splash water proof)
Weight: 1.3 kg
