Woodward|EASYGEN-3000|Genset Control Module
Woodward EASYGEN-3000 Genset Control
Description
The EASYGEN-3000 is a Sophisticated Control System designed for generator sets, providing comprehensive monitoring and control functionalities. It ensures reliable operation, efficient performance, and ease of use in various industrial applications. The system supports both the EASYGEN-3100 and EASYGEN-3200 models, each tailored for different mounting and operational requirements.
Features
- Supports multiple application modes: Start/Stop, Open GCB, Open/Close GCB, Open/Close GCB/MCB.
- Offers three operating modes: STOP, MANUAL, and AUTOMATIC.
- Equipped with static-sensitive electronic controls to prevent damage.
- Provides detailed navigation and configuration options via an intuitive front panel display.
- Includes safety features such as overspeed, overtemperature, and overpressure shutdown devices.
- Compatible with 1 A and 5 A measuring inputs.
- Designed for switch cabinet back mounting (EASYGEN-3100) and front-panel flush-mounting (EASYGEN-3200).
Technical Specifications
Model Numbers:
- EASYGEN-3100: For switch cabinet back mounting
- EASYGEN-3200: For front-panel flush-mounting
Power Supply:
- 100 VAC and 400 VAC inputs
Measuring Inputs:
- CTs, current transformers, secondary: 1 A or 5 A
Mounting:
- EASYGEN-3100: Switch cabinet back mounting
- EASYGEN-3200: Front-panel flush-mounting
Display and Controls:
- EASYGEN-3200 features a Liquid Crystal Display (LCD) and push buttons for navigation and operation
- EASYGEN-3100 has two LEDs on the front plate:
- COMMS LED: Not functional
- RUN LED: Green when energized and ready; Red when a shutdown alarm is present
Safety and Precautions:
- Equipped with independent overspeed, overtemperature, and overpressure shutdown devices
- Avoid using plastic, vinyl, and Styrofoam (except antistatic versions) around printed circuit boards
- Do not touch components or conductors on printed circuit boards with hands or conductive devices
Operating Temperature:
- -20°C to +60°C
Weight:
- EASYGEN-3200: Approximately 1.6 kg
Communication:
- RS-232, RS-485
Protection Rating:
- IP65, suitable for harsh environments
Alarm Management:
- Shutdown alarms (Class C, D, E, or F) trigger red RUN LED
- Alarms can stop the engine and open/close the GCB
LogicsManager:
- Configurable via softkeys for parameter selection, confirmation, and changes
- Help screen available for logical operators
