ABB |PNI800|Plant Network Interface module

SKU: PNI800

Manufacturer: ABB
Product No.: PNI800
Condition：In stock
Product Type: Plant Network Interface module
Product Origin: USA
Payment:T/T, Western Union
Weight: 550g
Shipping port: Xiamen
Warranty: 12 months

Description

The PNI800 is a Plant Network Interface module designed for real-time communications between SD Series Controllers and PC workstations. It supports bi-directional, real-time data exchange with S+ Engineering, HMI (SPO or 800xA Operations), and general-purpose interface software like the Harmony OPC Server. Part of ABB's Symphony® Plus control systems, the PNI800 ensures reliable and efficient communication in industrial automation environments.

Features

Real-Time Communications: Supports bi-directional, real-time data exchange.
Redundancy: Implements IEC 62439 Parallel Redundancy Protocol (PRP) for network reliability.
Virtualized Option: Available as "VPNI" software for SPE engineering, SPO & 800xA Operations HMI, and general-purpose interface software.
Hot Swap Capability: Allows for easy maintenance and upgrades without system downtime.
Diagnostics Port: Mini USB form factor on the module front plate for diagnostics.
Mounting: Horizontal Row, xA Style (186mm).

Technical Specifications

Article Number: PNI800K01
Life Cycle Status: Active
Protocol: Harmony API (Ethernet TCP)
Communication Type: Realtime Data Server
Capacity:
- Up to 10 SPE client connections
- Up to 30,000 HMI tags
Transmission Speed: 100 MBps
Communication Connections: Ethernet 2x RJ45 connectors on MB805 base
Diagnostics Port: 1x mini USB form factor on module front plate
Line Redundancy: Yes (via PRP)
Module Redundancy: No
Hot Swap: Yes
Form Factor: xA Style (186mm)
Mounting: Horizontal Row
HN800 Bus Length: n/a
MTBF (MIL-HDBK-217-FN2):
- PNI800 PR: G = 135,873 hours
- MB805 PR: E = 2,583,516 hours
MTTR (Hours):
- PNI800 MTTR = 1 hour
- MB805 MTTR = 8 hours
Processor Type: MCF5475 @ 256 MHz
Memory:
- 64 MB DRAM
- 4 MB Flash ROM
Module Power Requirements: 200 mA @ 24 VDC ±10%
Module Power Connection: TB1 on MB805 base
Overvoltage Category: Category 1 for power (tested according to IEC/EN 61010-1)
Mounting Details: MB805, 1 = E, 2 = C
Environmental and Certification:
- Operating Temperature: 0 to +55 °C
- Storage Temperature: -40 to +85 °C
- Relative Humidity: 20% to 95% @ 40°C non-condensing
- Protection Class: IP20 (EN 60529, IEC 529)
- Vibration (Operational Sinusoidal): 5 to 60 Hz 0.137 mm (0.0054 in.), 60 to 150 Hz 1.0 G
- Vibration (Transportation): 10 to 500 Hz
- Shock (Storage): 15 G, 11 msec
- Drop Test: 100 mm
- Altitude (Operational): Sea level to 3,048 meters (10,000 ft.)
- Altitude (Storage): Sea level to 12,192 meters (40,000 ft.)
- Air Quality: ISA S71.04 G1 (Standard), cRBX01A (Enhanced) ISA S71.04 G3 compliant version modules available
- ESD Immunity: Severity level 3 (IEC/EN 61000-6-2, IEC/EN 61000-4-2)
- Surge Immunity: Severity level 3 (IEC/EN 61000-6-2, IEC/EN 61000-4-5)
- Electrical Fast Transient Immunity: Severity level 3 (IEC/EN 61000-6-2, IEC/EN 61000-4-4)
- Radiated RFI Immunity: Severity level 3 (IEC/EN 61000-6-2, IEC/EN 61000-4-3)
- Conducted Immunity: Severity level 3 (IEC/EN 61000-6-2, IEC/EN 61000-4-6)
- Magnetic Field Immunity: Severity level 4 (IEC/EN 61000-6-2, IEC/EN 61000-4-8)
- Radiated Emission: Group 1, Class A, ISM equipment (IEC/EN 61000-6-4, CISPR 11 + A1, CISPR 16-1-1)
- Conducted Emission: Group 1, Class A, ISM equipment (IEC/EN 61000-6-4, CISPR 11 + A1, CISPR 16-1-1)
- Voltage Dips and Interruption Immunity: IEC/EN 61000-6-2, IEC/EN 61000-4-11
- Certifications:
  - CSA non-hazardous locations
  - CSA hazardous, nonincendive locations: Class I, Division 2, Groups A, B, C, D
  - CE Mark: EMC directive 2004/108/EC & Low Voltage Directive 2006/95/EC
  - RoHS Compliance: Directive 2015/863
  - WEEE Compliance: DIRECTIVE/2012/19/EU
Dimensions:
- Width: 59 mm
- Height: 186 mm
- Depth: 127 mm
Weight (include base): 500 g
